Home > Thermodynamics > Heat exchanges > ET600

Unit of transfers of material gas / liquid


Service : 220 V - 50 Hz; Network water
Dry air, flow 2 m3 / h
Dimensions : 760 x 730 x 360 mm

Print / download the product sheet
DEMANDER UN DEVIS POUR CETTE MACHINE

This device allows a simple approach to material transfer. It consists mainly of a column with wet discs. Water trickles down this column, while air is flowing countercurrently. In contact with the disks, the air becomes moist and the coefficient of material transfer between the liquid and the gas is calculated simply from the measurement of the air flow and its humidity. The water content of the air is determined by means of a hygrometer. The air and water flow rates as well as the dry and humid air temperatures and the water temperatures at various points of the apparatus are measured.




Technical specifications :
  • Determination of the gas phase mass transfer coefficient
  • Influence of gas flow on the material transfer coefficient
  • Influence of gas flow on exchange efficiency
  • Influence of gas flow on the number of transfer units
  • Determination of the heat transfer coefficient.
  • Technical specifications


    The apparatus includes :



  • 1 column with wet discs (exchange surface: 51.7 cm2)
  • 1 filter
  • 2 solenoid valves
  • 2 flowmeters
  • 1 manometer
  • 1 hygrometer
  • 5 temperature probes
  • 1 digital indicator
  • 1 regulator
  • 1 chassis
DEMANDER UN DEVIS POUR CETTE MACHINE

Other machines associated with the category Heat exchanges
Studies of the modes of transmission of heat
ET100
Read more
Study of radiation and natural convection
ET130
Read more
Apparatus for studying temperature measurements
ET301
Read more
Study group of the adiabatic gas law
ET1010
Read more
Apparatus for studying the ideal gas law and the principle of the thermal engine
ET1020
Read more
Thermal radiation study group
ET1030
Read more
Study of measurements of the thermophysical characteristics of materials
SERIE EI700
Read more
Study of measurements of the thermophysical characteristics of materials
EI701
Read more
Study of measurements of the thermophysical characteristics of materials
